5020 DC Blower
DC blower delivers high airflow in a compact form factor. Equipped with precision dual ball bearings and pure copper winding motor for extended service life. Ideal for space-constrained cooling applications.
Specifications
| Model | DB5020 |
| Name | 5020 DC Blower |
| Size | 50x50x20MM |
| Voltage | 12V-24V |
| Speed | 4000–7500 RPM |
| Air Flow | 3.59–7.02CFM |
| Static Pressure | 4.90–23.72mmAq |
| Noise | 26.8–39.4dBA |
| Motor | DC Brushless Outer Rotor Motor |
| Bearing | Dual Ball Bearing |
| Insulation Class | Class A |
QUALITY CERTIFICATE | SUPER WATERPROOF | INTELLIGENT CONTROL
Applications
- Medical Equipment
- Medical Cosmetology
- Power Supply
- Light Source
- Robotics
- Computer Chassis
- Power Supply
- Drone
- Industrial Computer
Product Type
Axial Fan, DC Fan, Small Fan, 50mm, Quiet Fan, Speed Control, Feedback
Dimension Drawings & Performance Curves
Need a Custom Solution?
Contact us for custom speed control, waterproof, or noise-reduction requirements.
